Type 2 to Schuko Socket Cable
The Type 2 Plug to Schuko Plug adapter is designed for powering public charging stations or wall-mounted charging boxes. It features a standard Schuko plug at one end, compatible with typical household sockets. This adapter facilitates charging for electric scooters, e-bikes, electric motorcycles, or electric wheelchairs.
Compatibility:
- Car Charger Side: Schuko
- Charger Side: Type 2
Features:
- Dual Current Ratings: Available in 16A and 32A variants to accommodate different charging capacities, meeting the diverse needs of electric vehicle owners.
- High-Quality Materials: Constructed with copper alloy pins featuring silver plating for enhanced conductivity and durability. The thermoplastic shell is flame retardant (UL94 V-0), ensuring safety.
- Electrical Performance: Withstands voltages up to 2000V, with insulation resistance exceeding 1000MΩ (DC500V) and maximum contact resistance of 0.5mΩ, ensuring reliable electrical connectivity.
- Temperature Resistance: Operates effectively in temperatures ranging from -30°C to +50°C, designed for frequent use with a no-load plug-in/pull-out capability of over 10,000 cycles.
- Robust Design: Features IP55 waterproof rating and withstands impact insertion forces greater than 300N, providing durability and reliability in various environmental conditions.
Specifications:
| Item | Type 2 Plug to Schuko Plug |
| Rated Operating Current | 16A/32A |
| Operation Voltage | AC 240V |
| Insulation Resistance | >1000MΩ(DC500V) |
| Withstand Voltage | 2000V |
| Pin Material | Copper Alloy, Silver Plating |
| Shell Material | Thermoplastic, Flame Retardant Grade UL94 V-0 |
| Operating Temperature | No-Load Plug-In / Pull-Out>10000 Times |
| Contact Resistance | 0.5mΩ Max |
| Terminal Temperature Rise | <50K |
| Operating Temperature | -30℃⁓+50℃ |
| Impact insertion Force | >300N |
| Waterproof Degree | IP55 |
| Cable Length | 16.4 FT (5Meter) |
| Cable Protection | Reliability of materials, antifoaming, pressure-resistant, abrasion resistance impact resistance, and high oil |
| Certification | CE ROHS |
